SONY 2053 2MP CMOS, capture images.
0.01Lux@(F1.2,AGC ON)，
IR-CUT switch ，CDS external control , D/N mode.
Support OSD menu ，suitable for user-defined settings.
Support UTC controller.
Support 12V voltage
Model No. | 1/2.7＂8536+2053 |
Video Format | PAL/NTSC |
Effective Resolution | 1920(H)x1080(V) |
Illumination | 0.0001Lux@(F1.2,AGC ON)，0LUX with IR |
Shutter | AUTO |
D/N Mode | External Control（Default）/Auto/Color/B&W |
Synchronization | inter-sync |
Frame rate | 1080P@25fps / 1080P@30fps |
Signal | AHD/TVI/CVI/CVBS (Optional) |
OSD Menu | |
Lens Mode | 2.8mm/2.1mm( optional) |
Exposure | Electronic Shutter/AGC/Frame /Brightness/DWDR/Fogging |
Back-light Mode | Close/Back-light Compensation/Strong Inhibition |
D/N Mode | External Control（Default）/Auto/Color/B&W |
Video Setting | Contrast/Sharpness/Saturation/DNR/Video Format/DWDR |
Working Temperature | -20℃ to 60℃ |
