Sony 1/3.2” Wide dynamic range.
High frame rate 60fps.
Defog function.
Strong light inhibition.
Wide voltage range.
Image Sensor | Sony 1/3.2” | Sony 1/3.2” |
TV System | PAL/NTSC (optional) | PAL/NTSC (optional) |
Picture Elements | 1280 (H) x 960 (V) | 1280 (H) x 960 (V) |
Sensitivity | 0 Lux (IR LED On) | 0 Lux (IR LED On) |
Scanning System | Progressive scan RGB CMOS | Progressive scan RGB CMOS |
Synchronization | Internal | Internal |
S/N Ratio | More than 46dB (AGC Off) | More than 46dB (AGC Off) |
Auto Gain Control (AGC) | Auto | Auto |
Electronic Shutter | Auto | Auto |
BLC | Auto | Auto |
Infrared Spectrum | 940nm | 940nm |
Infrared LED | 8 LEDs | 8 LEDs |
Video Output | 1 Vp-p, 75Ω,AHD | 1 Vp-p, 75Ω,AHD |
Audio | N/A | N/A |
Mirror | Available | Available |
ICR | N/A | N/A |
Noise Reduction | 3D | 3D |
Dynamic range | 120 dB | 120 dB |
Lens | f2.5mm Megapixel | F3.6mm Megapixel |
Power Supply | 9-24V DC | 9-24V DC |
Power Consumption | 150mA | 150mA |
Dimensions | 100 x 85 x 97 mm | |
Weatherproof/Water Proof | IP67 | |
Operating Temperature | -30° C ~ +70 ° C | |
