Screen Size : 10.1 inch
Resolution : IPS 1024（RGB）*600
Image Area：154.21(H)x85.92(V)
Viewing Angle：IPS
Brightness：500(TYP.)
Interface ：LVDS
Backlight：White light LED
Working Temperature：-10℃—+60℃
Storage Temperature ：-20℃—+70℃
Solution : Hi 3520 V300
OSD : Overlay display of time, date, border, channel character
Operation Mode : IR remote controller , auto trigger
Language : Chinese / English
Video Compression : H.264
Video Input : 4ch AHD 1080P / 960P / 720P input
4ch CVBS input ，compatible with CVBS and AHD signals，
compatible with PAL and NTSC systems
Video Output : 40pin\50pin（TTL\LVDS ）interface , 1024 * 600 resolution ( other interfaces can be customized , too. )
Display Mode : 12 display modes , support full screen mode of each channel
Boot Screen：3 split mode, dual mode , power –off memory are optional
Recording Resolution：1920*1080
Output Resolution：1920*1080, 1280*720, 1024*768, 800*600
Recording Quality：Ultra HD, HD, Standard, Ordinary are adjustable
Record Mode： 3 split mode, Dual mode ；
Video Mode: automatic record mode, delay-off 24h record mode
Storage： 2G-256G TF card
Video Playback :online playback or playback on computer ( Use USB to back the files or use professional player )
Power Management：Adaptive wide voltage input, reverse short circuit / low voltage / high voltage protection , etc.
Working Voltage：DC11.6V-36V
Power Consumption ：<7W（ doesn’t include 4pcs cameras ）
Working Temperature：-30°C~+70°C
